Smooth Bore Ring Gages

FEDERAL

.81315 MASTER PLAIN BORE RING GAGE .8125 +.0007 OVERSIZE 13/16 20.654 mm CHECK - DW15438AP1

1.5629 MASTER PLAIN BORE RING GAGE 1.5625 +.0004 1 9/16 39.698 INSPECTION CHECK - DW15431AP1

41.093 CLASS XX MASTER PLAIN BORE RING GAGE 41.000 +.093 OVERSIZE 41 mm 1.6178 - DW15440AP1

.520 CL Z MASTER PLAIN BORE RING GAGE .5313 -.0113 17/32 13.208 mm .5200 NO GO - DW15394LVR

KEES

.7450 CL Z MASTER PLAIN BORE RING GAGE .7500 -.0050 3/4 19 mm .745 NO GO CHECK - DW15402LVR

.985 CL Z MASTER PLAIN BORE RING GAGE .9844 +.0006 63/64 25 mm .9850 NO GO CHECK - DW15387LVR

.4960 CL X MASTER PLAIN BORE RING GAGE .5000 -.0040 1/2 12.598 mm .496 NO GO - DW15400LVR

.985 CL Z MASTER PLAIN BORE RING GAGE .9844 +.0006 63/64 25 mm .9850 NO GO CHECK - DW15393LVR

KEES

.7450 CL Z MASTER PLAIN BORE RING GAGE .7500 -.0050 3/4 19 mm .745 NO GO CHECK - DW15386LVR

.530 CL Z MASTER PLAIN BORE RING GAGE .5313 -.0013 17/32 13.462 mm .5300 CHECK - DW15385LVR

KEES

.5558 CL Z MASTER PLAIN BORE RING GAGE .5625 -.0067 UNDERSIZE 9/16 14 mm NO GO - DW15396LVR

KEES

.7570 CL Z MASTER PLAIN BORE RING GAGE .7500 +.0070 OVERSIZE 3/4 19.228 mm .757 - DW15389LVR
