Smooth Pin Plug Gages

1.4530 & 1.4570 CL X PIN PLUG GAGE GO NO GO 1.4531 -.0001 1 29/64 37 1.453 1.457 - CO0009BY4

.9800 & .9960 CL X PIN PLUG GAGE GO NO GO 1.0000 -.0040 1.0 25 mm .980 .996 - CO0008BY4

1.2386 & 1.2542 CL X PIN PLUG GAGE GO NO GO 1.2500 +.0042 OVERSIZE 1 1/4 32 mm - CO0006BY4

1.2520 & 1.2676 CL X PIN PLUG GAGE GO NO GO 1.2500 +.0020 1 1/4 32 mm 1.252 - CO0005BY4

1.0120 & 1.0160 CL X PIN PLUG GAGE GO NO GO 1.0156 +.0004 1 1/64 26 1.012 1.016 - CO0004BY4

1.0284 & 1.0424 CL X PIN PLUG GAGE GO NO GO 1.0313 -.0029 1 1/32 26 mm CHECK - CO0003BY4

.9970 & .9990 CL XX PIN PLUG GAGE GO NO GO 1.0000 -.0010 1.0 25.324 mm .997 .999 - CO0002BY4

VERMONT GAGE

.2500 CLASS Z PIN PLUG GAGE ONSIZE 1/4 6.350 mm .250 INSPECTION CHECK .25 0.25 - CO0001BY4

.9402 & .9418 PIN PLUG GAGE GO NO GO .9375 +.0027 OVERSIZE 15/16 24 mm CHECK - DW30081LVR

.6015 CLASS Z PIN PLUG GAGE .5938 +.0077 OVERSIZE 19/32 15.278 mm INSPECTION - DW30080LVR

1.9830 & 1.9950 PIN PLUG GAGE GO NO GO 1.9844 -.0014 1 63/64 50.673 1.983 1.995 - DW30078LVR

62.980 CLASS Y METRIC PIN PLUG GAGE 63.000 -.020 UNDERSIZE 63 mm 2.4795 62.98 - DW30077LVR
