Smooth Pin Plug Gages

MASTER

10.4991 CLASS XX PIN PLUG GAGE 10.5000 -.0009 UNDERSIZE 10 1/2 266.677 mm MASTER - DW30063BG4

MASTER

7.2499 CLASS XX PIN PLUG GAGE 7.2500 -.0001 UNDERSIZE 7 1/4 184 mm MASTER

3.3009 CLASS XX PIN PLUG GAGE 3.2969 +.0040 UNDERSIZE 3 19/64 84 mm MASTER SET - DW30059BG4

1.0005 CLASS XX PIN PLUG GAGE 1.0000 +.0005 OVERSIZE 1.0 25.413 mm INSPECTION - DW30047BG4

.3125 & .3129 CLASS X PIN PLUG GAGE GO NO GO ONSIZE 5/16 8 mm INSPECTION CHECK - JC4724BA4

.3820 & .3823 CL XX PIN PLUG GAGE GO NO GO .3750 +.0070 3/8 9.710 mm .382 CHECK - JC4723BA4

.3360 & .3380 CL X PIN PLUG GAGE GO NO GO .3438 -.0058 11/32 8.585 mm .336 .338 - JC4722BA4

.8790 & .8850 CL Y PIN PLUG GAGE GO NO GO .8750 +.0040 7/8 22.327 mm .879 .885 - JC4721BA4

.6500 & .6600 CL X PIN PLUG GAGE GO NO GO .6563 +.0037 21/32 16.764 mm .650 .660 - JC4720BA4

.8540 & .8550 CL X PIN PLUG GAGE GO NO GO .8438 +.0102 27/32 21.717 mm .854 .855 - JC4719BA4

.6290 & .6350 CL Y PIN PLUG GAGE GO NO GO .6250 +.0040 5/8 16 mm .629 .635 CHECK - JC4718BA4

.3740 & .3750 PIN PLUG GAGE GO NO GO ONSIZE 3/8 9.525 .374 .375 INSPECTION CHECK - JC4717BA4
