Smooth Pin Plug Gages

.3445 & .3447 CL XX PIN PLUG GAGE GO NO GO .3438 +.0007 11/32 8.755 INSPECTION - JC4603AZ4

.1239 & .1289 CLASS Z PIN PLUG GAGE GO NO GO .1250 -.0011 UNDERSIZE 1/8 3 mm - JC4602AZ4

4.940 & 4.970 CL XX METRIC PIN PLUG GAGE GO NO GO 5.000 -.030 5 .1945 4.94 4.97 - JC4601AZ4

.0250 & .0330 PIN PLUG GAGE GO NO GO .0313 +.0017 OVERSIZE 1/32 1 mm .025 .033 - JC4600AZ4

.1556 & .1559 CLASS X PIN PLUG GAGE GO NO GO .1563 -.0004 UNDERSIZE 5/32 4 mm - JC4599AZ4

.3917 & .3937 CL X PIN PLUG GAGE GO NO GO .3906 +.0011 UNDERSIZE 25/64 10 mm - JC4598AZ4

1.1016 & 1.1023 CL X PIN PLUG GAGE GO NO GO 1.0938 +.0078 1 3/32 28 INSPECTION - JC4597AZ4

.1562 & .1567 CLASS Z PIN PLUG GAGE GO NO GO .1563 -.0001 UNDERSIZE 5/32 4 mm - JC4596AZ4

.0420 & .0470 PIN PLUG GAGE GO NO GO .0469 +.0001 OVERSIZE 3/64 1 mm .042 .047 - JC4589AZ4

17.010 & 17.030 CL XX mm PIN PLUG GAGE GO NOGO 17.000 +.010 17 .6697 17.01 17.03 - JC4588AZ4

.1873 & .1878 CL X PIN PLUG GAGE GO NO GO .1875 -.0002 UNDERSIZE 3/16 4.770 mm - JC4587AZ4

1.1251 & 1.1260 CL X PIN PLUG GAGE GO NO GO 1.1250 +.0001 1 1/8 28.600 mm 1.126 - JC4586AZ4
