Smooth Pin Plug Gages

HEMCO

.6957 & .6976 CL X PIN PLUG GAGE GO NO GO .6875 +.0082 11/16 17.719 mm CHECK - JC4585AZ4

1.4000 CL XX MASTER SETTING DISC 1.4063 -.0063 UNDERSIZE 1 13/32 35.560 mm 1.400 - BR6057AW4

1.7000 CLASS XX MASTER SETTING DISC 1.7031 -.0031 OVERSIZE 1 45/64 43 mm 1.700 - BR6056AW4

1.9200 CL XX MASTER SETTING DISC 1.9219 -.0019 OVERSIZE 1 59/64 48.768 mm 1.920 - BR6055AW4

1.4100 CLASS XX MASTER SETTING DISC 1.4063 +.0037 OVERSIZE 1 13/32 36 mm 1.410 - BR6054AW4

1.4200 CLASS XX MASTER SETTING DISC 1.4219 -.0019 OVERSIZE 1 27/64 36 mm 1.420 - BR6053AW4

1.0050 CLASS XX MASTER SETTING DISC 1.0000 +.0050 OVERSIZE 1.0 25.527 mm 1.005 - BR6052AW4

1.0290 CLASS XX MASTER SETTING DISC 1.0313 -.0023 UNDERSIZE 1 1/32 26 mm 1.029 - BR6051AW4

.8800 CLASS XX MASTER SETTING DISC .8750 +.0050 OVERSIZE 7/8 22.352 mm .880 - BR6050AW4

1.1200 CL XX MASTER SETTING DISC 1.1250 -.0050 UNDERSIZE 1 1/8 28.448 mm 1.120 - BR6049AW4

1.1600 CL XX MASTER SETTING DISC 1.1563 +.0037 OVERSIZE 1 5/32 29.464 mm 1.160 - BR6048AW4

.9060 CLASS XX MASTER SETTING DISC .9063 -.0003 UNDERSIZE 29/32 23 mm .906 CHECK - BR6047AW4
