Smooth Pin Plug Gages

.1600 & .1640 PIN PLUG GAGE GO NO GO .1563 +.0037 OVERSIZE 5/32 4 mm .160 .164 - JC3089AL4

.1640 & .1670 PIN PLUG GAGE GO NO GO .1563 +.0077 OVERSIZE 5/32 4 mm .164 .167 - JC3085AL4

.1640 & .1670 PIN PLUG GAGE GO NO GO .1563 +.0077 OVERSIZE 5/32 4 mm .164 .167 - JC3084AL4

.1920 & .1960 PIN PLUG GAGE GO NO GO .1875 +.0045 OVERSIZE 3/16 5 mm .192 .196 - JC3083AL4

.1640 & .1670 PIN PLUG GAGE GO NO GO .1563 +.0077 OVERSIZE 5/32 4 mm .164 .167 - JC3082AL4

.1100 & .1140 CL Y PIN PLUG GAGE GO NO GO .1094 +.0006 7/64 3 mm .110 .114 CHECK - JC3081AL4

.0800 & .0820 PIN PLUG GAGE GO NO GO .0781 +.0019 UNDERSIZE 5/64 2 mm .080 .082 - JC3072AL4

.0900 & .0930 CL Y PIN PLUG GAGE GO NO GO .0938 -.0008 3/32 2.286 mm .090 .093 - JC3076AL4

.1170 & .1200 CL Y PIN PLUG GAGE GO NO GO .1250 -.0050 1/8 3 mm .117 .120 CHECK - JC3080AL4

.0805 & .0820 PIN PLUG GAGE GO NO GO .0781 +.0024 UNDERSIZE 5/64 2 mm .082 CHECK - JC3071AL4

.0860 & .0900 CL Y PIN PLUG GAGE GO NO GO .0938 -.0038 3/32 2 mm .086 .090 CHECK - JC3075AL4

.1140 & .1160 PIN PLUG GAGE GO NO GO .1250 -.0090 UNDERSIZE 1/8 3 mm .114 .116 - JC3079AL4
