Smooth Pin Plug Gages

1.8050 PIN PLUG GAGE 1.8125 -.0075 UNDERSIZE 1 13/16 46 mm 1.805 INSPECTION

1.151&1.157 CL ZZ PIN PLUG GAGE GO NO GO 1.1563 +.0007 1 5/32 29.235 1.151 1.157 - CB4035LVR

2.3045 & 2.3050 CL X PIN PLUG GAGE GO NO GO 2.3125 -.0075 2 5/16 58.547 2.305 - CB4032RDT

1.3926 & 1.3931 CL X PIN PLUG GAGE GO NO GO 1.3906 +.0020 1 25/64 35.372 mm - CB4031RDT

.9675 & .9680 CL X PIN PLUG GAGE GO NO GO .9688 -.0008 31/32 24.587 mm .968 - CB4034RDT

.3765 & .3785 PIN PLUG GAGE GO NO GO .3750 +.0015 OVERSIZE 3/8 9.614 mm CHECK - JC3137AL4

.8020 & .8070 CL Z PIN PLUG GAGE GO NO GO .8125 -.0055 13/16 20.371 mm .802 .807 - JC3136AL4

.2500 & .2510 PIN PLUG GAGE GO NO GO ONSIZE 1/4 6.350 .250 .251 INSPECTION CHECK - JC3129AL4

.7977 & .8125 PIN PLUG GAGE GO NO GO ONSIZE 13/16 20.262 mm INSPECTION CHECK - JC3135AL4

.2500 & .2515 PIN PLUG GAGE GO NO GO ONSIZE 1/4 6.350 mm .250 INSPECTION CHECK - JC3128AL4

.2420 & .2440 CL Z PIN PLUG GAGE GO NO GO .2500 -.0060 1/4 6 mm .242 .244 CHECK - JC3134AL4

.2550 & .2570 PIN PLUG GAGE GO NO GO .2500 +.0050 1/4 6.528 mm .255 .257 CHECK - JC3127AL4
