Smooth Pin Plug Gages

.3344 & .3418 PIN PLUG GAGE GO NO GO .3438 -.0020 UNDERSIZE 11/32 8.682 mm CHECK - JC3158AL4

.1140 & .1160 PIN PLUG GAGE GO NO GO .1250 -.0090 UNDERSIZE 1/8 3 mm .114 .116 - JC3143AL4

.1600 & .1640 PIN PLUG GAGE GO NO GO .1563 +.0037 OVERSIZE 5/32 4 mm .160 .164 - JC3157AL4

.2390 & .2430 PIN PLUG GAGE GO NO GO .2500 -.0070 UNDERSIZE 1/4 6 mm .239 .243 - JC3152AL4

.2405 & .2435 PIN PLUG GAGE GO NO GO .2500 -.0065 UNDERSIZE 1/4 6 mm INSPECTION - JC3148AL4

.2350 & .2450 PIN PLUG GAGE GO NO GO .2344 +.0006 UNDERSIZE 15/64 6 mm .235 .245 - JC3147AL4

SOSSNER

.1100 & .1140 CL Y PIN PLUG GAGE GO NO GO .1094 +.0006 7/64 3 mm .110 .114 CHECK - JC3142AL4

.5670 & .5770 CL Z PIN PLUG GAGE GO NO GO .5781 -.0011 37/64 14.656 mm .567 .577 - BT3838AL4

1.4970 & 1.5000 PIN PLUG GAGE GO NO GO ONSIZE 1 1/2 38 mm 1.497 1.500 CHECK - BT3837AL4

.3573 & .3663 CL Z PIN PLUG GAGE GO NO GO .3594 -.0021 23/64 9 EXTRA LONG GO - BT3827AL4

.5600 & .5700 CL Z PIN PLUG GAGE GO NO GO .5625 -.0025 9/16 14.224 mm .560 .570 - BT3836AL4

.5670 & .5770 CL Z PIN PLUG GAGE GO NO GO .5781 -.0011 37/64 14.656 mm .567 .577 - BT3835AL4
