Smooth Pin Plug Gages

12.6238 & 12.6488 CL Y METRIC PIN PLUG GAGE GO NO GO 13.000 -.351 13 mm .4980 - SR0031LVR

.5000 & .5050 PIN PLUG GAGE GO NO GO ONSIZE 1/2 13 mm .500 .505 INSPECTION - SR0030LVR

.0610 & .0650 CL X PIN PLUG GAGE GO NO GO .0625 -.0015 1/16 1.651 mm .061 .065 - SR0029LVR

.2710 & .2900 PIN PLUG GAGE GO NO GO .2813 +.0087 OVERSIZE 9/32 7 mm .271 .290 - SR0027LVR

.2651 & .2686 PIN PLUG GAGE GO NO GO .2656 -.0005 UNDERSIZE 17/64 7 mm CHECK - SR0025LVR

.9520 & .9720 CL X PIN PLUG GAGE GO NO GO .9531 -.0011 61/64 24 mm .952 .972 - SR0023LVR

.6380 & .6480 CL Z PIN PLUG GAGE GO NO GO .6406 -.0026 41/64 16.205 mm .638 .648 - SR0024LVR

DUNDICK

1.5960 & 1.6160 CL Z PIN PLUG GAGE GO NO GO 1.5938 +.0022 1 19/32 41 1.596 1.616 - SR0021LVR

.0660 & .0700 PIN PLUG GAGE GO NO GO .0625 +.0035 1/16 1.778 mm .066 .070 - SR0018LVR

.0930 & .0970 PIN PLUG GAGE GO NO GO .0938 -.0008 3/32 2.362 mm .093 .097 - SR0016LVR

4.200 & 4.500 CLASS ZZ METRIC PIN PLUG GAGE GO NO GO ONSIZE 5 mm .1654 4.20 4.50 - SR0020LVR

.0610 & .0650 PIN PLUG GAGE GO NO GO .0625 -.0015 1/16 1.651 mm .061 .065 CHECK - SR0017LVR
