Smooth Pin Plug Gages

1.0610 & 1.0620 CL Y PIN PLUG GAGE GO NO GO 1.0625 -.0005 1 1/16 27 1.061 1.062 - MW0032CN4

2.4058 & 2.4070 CL X PIN PLUG GAGE GO NO GO 2.4063 -.0005 2 13/32 61 mm 2.407 - MW0031CN4

1.2500 & 1.2510 CL Y PIN PLUG GAGE GO NO GO ONSIZE 1 1/4 31.775 mm 1.250 1.251 - MW0030CN4

1.0040 & 1.0070 PIN PLUG GAGE GO NO GO 1.0000 +.0040 1.0 25.578 mm 1.004 1.007 - MW0029CN4

1.4567 & 1.4571 CL Y PIN PLUG GAGE GO NO GO 1.4531 +.0036 1 29/64 37 mm CHECK - MW0028CN4

1.2425 CLASS X PIN PLUG GAGE 1.2500 -.0075 UNDERSIZE 1 1/4 31.560 mm INSPECTION - MW0027CN4

.3125 & .3135 CLASS Y PIN PLUG GAGE GO NO GO ONSIZE 5/16 8 mm INSPECTION CHECK - MW0026CN4

2.0000 CLASS XX PIN PLUG GAGE ONSIZE 2.0 50.800 mm 2.000 INSPECTION TOOLING - MW0025CN4

1.3780 CLASS Z PIN PLUG GAGE 1.3750 +.0030 OVERSIZE 1 3/8 35 mm 1.378 CHECK - MW0024CN4

1.8040 CLASS X PIN PLUG GAGE 1.8125 -.0085 UNDERSIZE 1 13/16 46 mm 1.804 CHECK - MW0023CN4

1.7450 & 1.7550 CL Y PIN PLUG GAGE GO NO GO 1.7500 -.0050 44.323 1.745 1.755 - MW0022CN4

BOICE

1.8750 & 1.8760 CL Y PIN PLUG GAGE GO NO GO ONSIZE 1 7/8 47.650 mm 1.875 1.876 - MW0021CN4
