Smooth Pin Plug Gages

.3070 & .3090 PIN PLUG GAGE GO NO GO .3125 -.0035 UNDERSIZE 5/16 8 mm .307 .309 - SR0019LVR

.1650 & .1665 CL X PIN PLUG GAGE GO NO GO .1563 +.0087 OVERSIZE 5/32 4 mm .165 - SR0015LVR

.3880 & .3960 PIN PLUG GAGE GO NO GO .3906 -.0026 25/64 10 mm .388 .396 CHECK - SR0014LVR

.7782 & .7912 PIN PLUG GAGE GO NO GO .7813 -.0031 UNDERSIZE 25/32 20 mm CHECK - SR0013LVR

.1180 & .1220 PIN PLUG GAGE GO NO GO .1250 -.0030 UNDERSIZE 1/8 3 mm .118 .122 - SR0012LVR

1.2510 & 1.2520 PIN PLUG GAGE GO NO GO 1.2500 +.0010 OVERSIZE 1 1/4 31.801 mm - SR0009LVR

.1390 & .1400 PIN PLUG GAGE GO NO GO .1406 -.0006 9/64 3.556 mm .139 .140 CHECK - SR0011LVR

.7505 & .7514 CLASS Y PIN PLUG GAGE GO NO GO .7500 +.0005 OVERSIZE 3/4 19 mm - SR0008LVR

.8995 & .9005 CL X PIN PLUG GAGE GO NO GO .9063 -.0058 UNDERSIZE 29/32 23 mm - SR0010LVR

.5001 & .5003 CL XX PIN PLUG GAGE GO NO GO .5000 +.0001 OVERSIZE 1/2 12.708 mm - SR0007LVR

.1980 & .2060 CL Y PIN PLUG GAGE GO NO GO .2031 +.0029 13/64 5 mm .198 .206 - SR0006LVR

.6245 & .6250 PIN PLUG GAGE GO NO GO ONSIZE 5/8 16 mm .625 INSPECTION - SR0005LVR
