Smooth Pin Plug Gages

.3690 & .3710 CL Z PIN PLUG GAGE GO NO GO .3750 -.0040 3/8 9.373 mm .369 .371 - BT0019LVR

.2640 & .2670 PIN PLUG GAGE GO NO GO .2656 +.0014 17/64 6.782 mm .264 .267 - BT0012LVR

.4840 & .4920 CL Y PIN PLUG GAGE GO NO GO .4844 -.0004 31/64 12.294 mm .484 .492 - BT0010LVR

.4270 & .4310 PIN PLUG GAGE GO NO GO .4375 -.0065 UNDERSIZE 7/16 11 mm .427 .431 - BT0009LVR

.3770 & .3800 CL X PIN PLUG GAGE GO NO GO .3750 +.0020 3/8 9.652 mm .377 .380 - BT0005LVR

.3880 & .3950 CL Y PIN PLUG GAGE GO NO GO .3906 -.0026 25/64 10 mm .388 .395 - BT0008LVR

.2515 & .2535 PIN PLUG GAGE GO NO GO .2500 +.0015 OVERSIZE 1/4 6.388 mm - BT0003LVR

.2505 & .2510 PIN PLUG GAGE GO NO GO .2500 +.0005 OVERSIZE 1/4 6.363 mm .251 - BT0006LVR

.1580 & .1595 CL ZZ PIN PLUG GAGE GO NO GO .1563 +.0017 OVERSIZE 5/32 4 mm .158 - BS0363RD

.4520 & .4550 PIN PLUG GAGE GO NO GO .4531 -.0011 29/64 11.557 mm .452 .455 - BS0369RD

.31496 & .31574 CLASS X PIN PLUG GAGE GO NO GO .3125 +.0025 OVERSIZE 5/16 8 mm - BS0364RD

VERMONT GAGE

.2500 CLASS ZZ PIN PLUG GAGE ONSIZE 1/4 6.350 mm .250 INSPECTION QUALITY CHECK - BS0361RD
