Smooth Pin Plug Gages

.3300 & .3400 CL Z PIN PLUG GAGE GO NO GO .3281 +.0019 21/64 8.636 mm .330 .340 - BR8133BR4

.4040 & .4140 PIN PLUG GAGE GO NO GO .4063 -.0023 13/32 10.262 mm .404 .414 - BR8132BR4

.4820 & .4920 CL Z PIN PLUG GAGE GO NO GO .4844 -.0024 31/64 12.243 mm .482 .492 - BR8131BR4

TRIPLE SEAL

.3300 & .3400 CL Z PIN PLUG GAGE GO NO GO .3281 +.0019 21/64 8.636 mm .330 .340 - BR8130BR4

9.000 CLASS ZZ METRIC PIN PLUG GAGE ONSIZE 9 mm .3543 9.00 INSPECTION CHECK - BR8045BR4

.5313 & .5332 CLASS X PIN PLUG GAGE GO NO GO ONSIZE 17/32 13.543 mm INSPECTION - CO0040BY4

.3180 & .3200 CL X PIN PLUG GAGE GO NO GO .3125 +.0055 5/16 8 mm .318 .320 CHECK - CO0039BY4

.5003 & .5017 CL X PIN PLUG GAGE GO NO GO .5000 +.0003 OVERSIZE 1/2 12.743 mm - CO0038BY4

.6300 & .6350 CL X PIN PLUG GAGE GO NO GO .6250 +.0050 5/8 16 mm .630 .635 CHECK - CO0037BY4

1.3010 & 1.3030 CL ZZ PIN PLUG GAGE GO NO GO 1.3125 -.0095 1 5/16 33 1.301 1.303 - CO0036BY4

1.1665 & 1.1685 CL X PIN PLUG GAGE GO NO GO 1.1719 -.0034 1 11/64 29.680 mm - CO0035BY4

1.8268 & 1.8287 CL X PIN PLUG GAGE GO NO GO 1.8281 +.0006 1 53/64 46.401 mm - CO0034BY4
