Measuring & Inspecting

.9800 & .9960 CL X PIN PLUG GAGE GO NO GO 1.0000 -.0040 1.0 25 mm .980 .996 - CO0008BY4

1.2386 & 1.2542 CL X PIN PLUG GAGE GO NO GO 1.2500 +.0042 OVERSIZE 1 1/4 32 mm - CO0006BY4

1.2520 & 1.2676 CL X PIN PLUG GAGE GO NO GO 1.2500 +.0020 1 1/4 32 mm 1.252 - CO0005BY4

1.0120 & 1.0160 CL X PIN PLUG GAGE GO NO GO 1.0156 +.0004 1 1/64 26 1.012 1.016 - CO0004BY4

1.0284 & 1.0424 CL X PIN PLUG GAGE GO NO GO 1.0313 -.0029 1 1/32 26 mm CHECK - CO0003BY4

.9970 & .9990 CL XX PIN PLUG GAGE GO NO GO 1.0000 -.0010 1.0 25.324 mm .997 .999 - CO0002BY4

VERMONT GAGE

.2500 CLASS Z PIN PLUG GAGE ONSIZE 1/4 6.350 mm .250 INSPECTION CHECK .25 0.25 - CO0001BY4

7.7500 CLASS X MASTER PLAIN BORE RING GAGE ONSIZE 7 3/4 197 mm 7.750 7.75 VTG - DW31285BQ4

7.0000 CLASS X MASTER PLAIN BORE RING GAGE ONSIZE 7.0 178 mm 7.000 7.00 SETTING - DW31284BQ4

6.5000 CLASS X MASTER PLAIN BORE RING GAGE ONSIZE 6 1/2 165 mm 6.500 6.50 6.5 - DW31283BQ4

6.0000 CLASS X MASTER PLAIN BORE RING GAGE ONSIZE 6.0 152.400 mm 6.000 6.00 VTG - DW31282BQ4

5.5276 CL Z MASTER PLAIN BORE RING GAGE 5.5313 -.0037 5 17/32 140.401 mm CHECK - DW31281BQ4
