Products

2 1/2 18 UNS 2A THREAD RING GAGES 2.5 2.50 GO NO GO P.D.'S = 2.4623 & 2.4570 - DW31575BZ4

GSG

5/8 11 UNC 2B 4 START THREAD PLUG GAGE .625 GO NO GO P.D.'S = .5660 & .5732 - DW31574LVR

1 1/8 7 UNC 2A LEFT HAND THREAD RING GAGES 1.125 GO NO GO PD'S = 1.0300 & 1.0228 - DW31573LVR

GSG

5/8 11 UNC 2A 4 START THREAD RING GAGES .625 GO NO GO P.D.'S = .5644 & .5589 - DW31572LVR

PRATT & WHITNEY

1 5/16 12 NS LEFT HAND THREAD RING GAGE 1.3125 GO ONLY P.D. = 1.2584 L.H. UN-3A - DW31571LVR

11/16 20 UNS 3A PREPLATE SET THREAD PLUG GAGE .6875 GO ONLY P.D. = .6465 CHECK - DW31570LVR

G3/4 14 BSPP PIPE THREAD PLUG GAGE .75 .750 GO NO GO P.D.'S = 25.279 & 25.421 - DW31569LVR

PMC

13/16 28 UN 2A HILO SET THREAD PLUG GAGE .8125 GO NO GO P.D.'S = .7881 & .7843 - DW31568LVR

9/16 20 UN 2A SET THREAD PLUG GAGE .5625 GO NO GO P.D.'S = .5287 & .5245 CHECK - DW31567LVR

SPI

1/16 27 NPT L1 PIPE THREAD PLUG GAGE .0625 N.P.T. NATIONAL TAPER INSPECTION - DW31565LVR

PM CO.

4" 12 NS 3 THREAD PLUG GAGE 4.0 4.00 4.000 4.0000 NO GO ONLY P.D. = 3.9518 CHECK - DW31564LVR

GODWIN

1/16 27 NPT L1 PIPE THREAD PLUG GAGE .0625 N.P.T. NATIONAL TAPER INSPECTION - DW31563LVR
