Pin Plug Gages

.525 & .526 CL X PIN PLUG GAGE GO NO GO .5313 -.0053 17/32 13.335 mm .5250 .5260 - MB0368AC1

.702 & .707 PIN PLUG GAGE GO NO GO .7031 -.0011 45/64 18 mm .7020 .7070 - MB0365AC1

BENDIX

.439 & .442 PIN PLUG GAGE GO NO GO .4375 +.0015 OVERSIZE 7/16 11 mm .4390 .4420 - MB0367AC1

.8781 & .880 PIN PLUG GAGE GO NO GO .8750 +.0031 OVERSIZE 7/8 22.304 mm .8800 - MB0372AC1

DUNDICK

.627 & .629 PIN PLUG GAGE GO NO GO .6250 +.0020 OVERSIZE 5/8 16 mm .6270 .6290 - MB0361AC1

.4987 & .500 PIN PLUG GAGE GO NO GO ONSIZE 1/2 12.700 mm .5000 .5 .50 - MB0377AC1

GTD

.4992 & .5000 PIN PLUG GAGE GO NO GO ONSIZE 1/2 12.700 mm .500 A-2 TAPERLOCK - MB0378AC1

DUNDICK

.733 & .735 PIN PLUG GAGE GO NO GO .7344 +.0006 47/64 18.669 mm .7330 .7350 - MB0344AC1

.4375 & .4387 PIN PLUG GAGE GO NO GO ONSIZE 7/16 11 mm .43750 .43870 - MB0359AC1

.8050 & .8150 CL Z PIN PLUG GAGE GO NO GO .8125 +.0025 13/16 20.701 mm .805 .815 - MB0342AC1

GTD

.513 & .518 PIN PLUG GAGE GO NO GO .5156 33/64 13 .5130 .5180 A-3 TAPERLOCK - MB0348AC1

G.A.CO

.497 & .498 PIN PLUG GAGE GO NO GO .5000 -.0020 1/2 12.649 mm .4970 .4980 - MB0354AC1
