Pin Plug Gages

.507 & .509 PIN PLUG GAGE GO NO GO .5000 -.0066 OVERSIZE 1/2 13 mm .5070 .5090 - JR0258AC1

.437 & .738 PIN PLUG GAGE GO NO GO .4375 -.0005 UNDERSIZE 7/16 11 mm .4370 .7380 - JR0235AC1

34.0 & 34.2 METRIC PIN PLUG GAGE GO NO GO ONSIZE 34 mm 1.3386 34.000 34.200 - JR0238AC1

1.247 & 1.248 PIN PLUG GAGE GO NO GO 1.2500 -.0020 1 1/4 31.699 mm 1.2470 1.2480 - JR0241AC1

DUNDICK

.702 & .703 PIN PLUG GAGE GO NO GO .7031 -.0001 OVERSIZE 45/64 18 mm .7020 .7030 - JR0252AC1

BENDIX BESLY

.404 & .406 PIN PLUG GAGE GO NO GO .4063 -.0003 13/32 10.262 mm .4040 .4060 - JR0245AC1

.5625 & .563 PIN PLUG GAGE GO NO GO ONSIZE 9/16 14.288 mm .5630 - JR0236AC1

GREENFIELD

.6245 & .625 PIN PLUG GAGE GO NO GO ONSIZE 5/8 16 mm .6250 - JR0242AC1

.874 & .875 CLASS X PIN PLUG GAGE GO NO GO ONSIZE 7/8 22 mm .8740 .8750 - JR0254AC1

S.C.C.

.631 & .633 PIN PLUG GAGE .6250 +.0060 5/8 16 mm .6310 .6330 - JR0203AC1

1.372 & 1.375 PIN PLUG GAGE GO NO GO ONSIZE 1 3/8 35 mm 1.3720 1.3750 - JR0156AC1

1.3405 & 1.3470 PIN PLUG GAGE GO NO GO 1.3438 +.0032 1 11/32 34 mm 1.347 - JR0172AC1
