Pin Plug Gages

MICRON

.905 & .911 CL Y PIN PLUG GAGE GO NO GO .9063 -.0013 29/32 23 mm .9050 .9110 - AR1653AF1

MICRON

1.216 & 1.219 CL Y PIN PLUG GAGE GO NO GO 1.2188 +.0002 1 7/32 31 1.2160 1.2190 - AR1658AF1

MICRON

1.316 & 1.317 CL X PIN PLUG GAGE GO NO GO 1.3125 +.0035 1 5/16 33.426 1.3160 1.3170 - AR1662AF1

MICRON

1.190 & 1.193 CL Y PIN PLUG GAGE GO NO GO 1.1875 +.0025 1 3/16 30.226 1.1900 1.1930 - AR1660AF1

MICRON

1.045 & 1.047 CL X PIN PLUG GAGE GO NO GO 1.0469 +.0001 1 3/64 26.594 1.0450 1.0470 - AR1669AF1

MICRON

1.378 & 1.382 CL Z PIN PLUG GAGE GO NO GO 1.3750 +.0030 1 3/8 35 1.3780 1.3820 - AR1666AF1

MICRON

1.156 & 1.159 CL Y PIN PLUG GAGE GO NO GO 1.1563 -.0003 1 5/32 29.362 1.1560 1.1590 - AR1659AF1

1.381 & 1.385 CL X PIN PLUG GAGE GO NO GO 1.3750 +.0060 1 3/8 35 1.3810 1.3850 - AR1640AG1

2.250 & 2.252 CLASS X PIN PLUG GAGE GO NO GO ONSIZE 2 1/4 57 mm 2.2500 2.2520 - AR1641AG1

1.7816 & 1.7820 CL XX PIN PLUG GAGE GO NO GO 1.7813 +.0003 1 25/32 45.253 1.782 - AR1634AG1

MICRON

1.050 & 1.055 CL Z PIN PLUG GAGE GO NO GO 1.0469 +.0031 1 3/64 26.797 1.0500 1.0550 - AR1648AF1

1.7816 & 1.7820 CL XX PIN PLUG GAGE GO NO GO 1.7813 +.0003 1 25/32 45.253 1.782 - AR1639AG1
