Pin Plug Gages

.6582 CLASS Z PIN PLUG GAGE .6563 +.0019 OVERSIZE 21/32 16.718 mm - MB2262AC1

QCS

.5770 & .5790 CL X PIN PLUG GAGE GO NO GO .5781 +.0009 37/64 14.707 mm .577 .579 - MB2266AC1

1.4995 PIN PLUG GAGE 1.5000 -.0005 UNDERSIZE 1 1/2 38 mm - MB2280AC1

.3748 & .375 CLASS XX PIN PLUG GAGE GO NO GO ONSIZE 3/8 9.525 mm .3750 - AR1585AG1

.3782 & .3798 CL Z PIN PLUG GAGE GO NO GO .3750 +.0032 OVERSIZE 3/8 9.647 mm - AR1586AG1

2.4375 & 2.4385 CLASS XX PIN PLUG GAGE GO NO GO ONSIZE 2 7/16 62 mm - AR1592AG1

.3118 & .3122 CLASS X PIN PLUG GAGE GO NO GO .3125 -.0003 UNDERSIZE 5/16 8 mm - AR1584AG1

.6171 & .618 CL X PIN PLUG GAGE GO NO GO .6250 -.0070 5/8 15.697 mm .6180 - AR1581AG1

.7515 & .7525 CLASS XX PIN PLUG GAGE GO NO GO .7500 +.0015 OVERSIZE 3/4 19 mm - AR1576AG1

.5915 & .5935 CL Y PIN PLUG GAGE GO NO GO .5938 -.0003 UNDERSIZE 19/32 15 mm - AR1577AG1

1.9995 & 2.0005 PIN PLUG GAGE GO NO GO 2.0000 -.0005 UNDERSIZE 2.0 51 mm - AR1588AG1

.5030 & .5049 CL Z PIN PLUG GAGE GO NO GO .5000 +.0030 OVERSIZE 1/2 13 mm .503 - AR1573AG1
