Pin Plug Gages

.8023 & .805 CL X PIN PLUG GAGE GO NO GO .8125 -.0075 13/16 20.378 mm .8050 - AR1566AG1

.686 & .689 CL Z PIN PLUG GAGE GO NO GO .6875 -.0015 11/16 17.424 mm .6860 .6890 - AR1571AG1

.654 & .656 CL Y PIN PLUG GAGE GO NO GO .6563 -.0003 21/32 16.662 mm .6540 .6560 - AR1556AG1

.7501 & .7505 CLASS X PIN PLUG GAGE GO NO GO .7500 +.0001 OVERSIZE 3/4 19 mm - AR1555AG1

.6170 & .618 CL X PIN PLUG GAGE GO NO GO .6250 -.0070 5/8 15.697 mm .617 .6180 - AR1560AG1

.5321 & .5330 CL X PIN PLUG GAGE GO NO GO .5313 +.0008 17/32 13.538 mm .533 - AR1570AG1

.7515 & .7525 CLASS XX PIN PLUG GAGE GO NO GO .7500 +.0015 OVERSIZE 3/4 19 mm - AR1565AG1

SOUTHERN GAGE CO.

.6251 & .6256 PIN PLUG GAGE GO NO GO .6250 +.0001 OVERSIZE 5/8 16 mm - AR1554AG1

HEMCO

6.6240 CLASS X PIN PLUG GAGE 6.6250 -.0010 UNDERSIZE 6 5/8 168.250 mm 6.624 - AR1473AC1

FEDERAL

6.3175 CLASS X PIN PLUG GAGE 6.3125 +.0050 OVERSIZE 6 5/16 160.465 mm - AR1474AC1

FEDERAL

6.1000 CLASS X PIN PLUG GAGE 6.0938 +.0062 OVERSIZE 6 3/32 155 mm 6.100 - MB2115AC1

BESLY

2.406 & 2.416 CL X PIN PLUG GAGE GO NO GO 2.4063 -.0003 2 13/32 61 2.4060 2.4160 - MB2111AC1
