Pin Plug Gages

.6865 & .688 CL Y PIN PLUG GAGE GO NO GO .6875 +.0005 11/16 17.437 mm .6880 - MB2080AC1

3.3650 PIN PLUG GAGE 3.3750 -.0100 UNDERSIZE 3 3/8 85.471 mm 3.365 - MB2074AC1

DUNDICK

.312 & .313 CL X PIN PLUG GAGE GO NO GO .3125 -.0005 5/16 8 mm .3120 .3130 - MB2053AC1

DUNDICK

.810 & .820 CL X PIN PLUG GAGE GO NO GO .8125 -.0025 13/16 21 mm .8100 .8200 - MB2066AC1

BENDIX BESLY

.3110 & .3115 PIN PLUG GAGE GO NO GO .3125 -.0010 UNDERSIZE 5/16 8 mm .311 - MB2056AC1

.5617 & .563 PIN PLUG GAGE GO NO GO .5625 +.0005 OVERSIZE 9/16 14.267 mm .5630 - MB2055AC1

DUNDICK

.373 & .374 CL X PIN PLUG GAGE GO NO GO .3750 -.0010 3/8 9.474 mm .3730 .3740 - MB2057AC1

DUNDICK

1.110 & 1.125 CLASS X PIN PLUG GAGE GO NO GO ONSIZE 1 1/8 28 mm 1.1100 1.1250 - MB2064AC1

.6870 & .6875 CLASS X PIN PLUG GAGE GO NO GO ONSIZE 11/16 17.450 mm .687 - MB2061AC1

.4985 & .501 PIN PLUG GAGE GO NO GO .5000 +.0010 OVERSIZE 1/2 12.725 mm .5010 - MB2068AC1

DUNDICK

.157 & .159 PIN PLUG GAGE GO NO GO .1563 +.0007 OVERSIZE 5/32 4 mm .1570 .1590 - MB2063AC1

.7845 & .7865 PIN PLUG GAGE GO NO GO .7813 +.0032 OVERSIZE 25/32 20 mm - MB2065AC1
