Pin Plug Gages

PRATT & WHITNEY

.531 & .532 PIN PLUG GAGE GO NO GO .5313 -.0003 17/32 13.513 .5310 .5320 A-3 TAPERLOCK - MB2039AC1

BENDIX

.458 & .478 PIN PLUG GAGE GO NO GO .4688 +.0092 OVERSIZE 15/32 12 mm .4580 .4780 - MB2037AC1

.4930 & .4940 PIN PLUG GAGE GO NO GO .5000 -.0060 1/2 12.548 mm .493 .494 - MB2031AC1

.191 & .194 CL Z PIN PLUG GAGE GO NO GO .1875 +.0035 3/16 5 mm .1910 .1940 - MB2034AC1

.185 & .186 PIN PLUG GAGE GO NO GO .1875 -.0015 3/16 4.724 mm .1850 .1860 - MB2044AC1

2.220 & 2.225 PIN PLUG GAGE GO NO GO 2.2188 +.0012 2 7/32 56.388 2.2200 2.2250 - AR1416AC1

DUNDICK

.7185 & .719 PIN PLUG GAGE GO NO GO .7188 +.0002 OVERSIZE 23/32 18.250 mm .7190 - AR1428AC1

2.010 & 2.012 PIN PLUG GAGE GO NO GO 2.0156 -.0036 2 1/64 51 mm 2.0100 2.0120 - AR1424AC1

HEMCO

.190 & .195 PIN PLUG GAGE GO NO GO .1875 +.0025 OVERSIZE 3/16 5 mm .1900 .1950 - AR1430AC1

STANDARD GAGE CO.

.3145 & .3155 PIN PLUG GAGE GO NO GO .3125 +.0020 OVERSIZE 5/16 8 mm - AR1432AC1

BESLY

.684 & .691 CL X PIN PLUG GAGE GO NO GO .6875 -.0035 11/16 17.374 mm .6840 .6910 - AR1420AC1

REGAL BELOIT

.190 & .196 CL X PIN PLUG GAGE GO NO GO .1875 +.0025 3/16 5 mm .1900 .1960 - AR1414AC1
