Pin Plug Gages

DUNDICK

1.062 & 1.063 CL X PIN PLUG GAGE GO NO GO 1.0625 -.0005 1 1/16 27 1.0620 1.0630 - AR1202AC1

1.9355 & 1.9375 PIN PLUG GAGE GO NO GO ONSIZE 1 15/16 49 mm - AR1213AC1

BENDIX BESLY

.249 & .250 PIN PLUG GAGE GO NO GO ONSIZE 1/4 6.325 mm .2490 .2500 - MB1791AC1

.314 & .315 PIN PLUG GAGE GO NO GO .3125 +.0015 OVERSIZE 5/16 8 mm .3140 .3150 - MB1789AC1

BESLY

.1825 & .1830 CL X PIN PLUG GAGE GO NO GO .1875 -.0045 3/16 4.648 mm .183 - MB1804AC1

TAFT-PEIRCE

.312 & .3125 PIN PLUG GAGE GO NO GO ONSIZE 5/16 8 mm .3120 - MB1795AC1

.263 & .267 CL Z PIN PLUG GAGE GO NO GO .2656 +.0014 17/64 6.782 mm .2630 .2670 - MB1799AC1

WOODWORTH

.8085 & .8095 PIN PLUG GAGE GO NO GO .8125 -.0030 UNDERSIZE 13/16 20.561 mm - MB1807AC1

.2507 & .2515 PIN PLUG GAGE GO NO GO .2500 +.0007 OVERSIZE 1/4 6.368 mm - MB1803AC1

.749 & .7505 PIN PLUG GAGE GO NO GO .7500 +.0005 OVERSIZE 3/4 19 mm .7490 - MB1798AC1

.3120 & .3125 PIN PLUG GAGE GO NO GO ONSIZE 5/16 8 mm .312 - MB1794AC1

DUNDICK

.139 & .147 CL X PIN PLUG GAGE GO NO GO .1406 -.0016 9/64 3.734 mm .1390 .1470 - MB1793AC1
