Thread Gages

SHOP MADE 5.19 12 UN 2B THREAD PLUG GAGE 5.190 5.1900 5.19"-12 INSPECTION CHECK - DW31900LVR

PRATT & WHITNEY

5" 12 N 3 THREAD PLUG GAGE 5.0 5.00 5.000 5.0000 NO GO ONLY P.D. = 4.9518 UN-3 - DW31899LVR

PRATT & WHITNEY

1 1/8 16 N 3 SET THREAD PLUG GAGE 1.125 1.1250 GO NO GO P.D.'S = 1.0844 & 1.0806 - DW31898LVR

3/4 18 UNS 2A THREAD RING GAGES .75 .750 .7500 GO NO GO P.D.'S = .7125 & .7079 - DW31897LVR

SWANSON

1" 11 1/2 NPT L1 PIPE THREAD RING GAGE 1.0 1.00 1.000 1.0000 N.P.T. NATIONAL - DW31896OB4

SWANSON

1 1/2 11 1/2 NPT L1 PIPE THREAD RING GAGE 1.5 1.50 1.500 1.5000 N.P.T. NATIONAL - DW31895OB4

SWANSON

3" 8 NPT L1 PIPE THREAD RING GAGE 3.0 3.00 3.000 3.0000 N.P.T. NATIONAL TAPER - DW31894OB4

TAFT PEIRCE

1 3/8 6 NC 3 THREAD RING GAGES 1.375 GO NO GO P.D.'S = 1.2667 & 1.2596 UNC-3 - DW31893CB4

TAFT PEIRCE

7/8 9 NC 5 THREAD RING GAGES .875 .8750 GO NO GO P.D.'S = .8093 & .8062 UNC-5 - DW31892CB4

WEDIN

1" 8 NC 5 THREAD RING GAGES 1.0 1.00 1.000 GO NO GO P.D.'S = .9253 & .9226 UNC-5 - DW31891CB4

ALAMEDA

1 1/4 7 UNC 3A THREAD RING GAGES 1.25 1.250 GO NO GO P.D.'S = 1.1572 & 1.1517 - DW31890CB4

TAFT PEIRCE

1 1/8 12 NF 5 THREAD RING GAGES 1.125 GO NO GO P.D.'S = 1.0776 & 1.0738 UNF-5 - DW31889CB4
