Thread Gages

SHOP MADE M100 X 2 SOLID THREAD RING GAGE 100 2.0 METRIC INSPECTION CHECK - DW30428LVR

SHOP MADE 1" 5 ACME THREAD PLUG GAGE 1.0 5. 1"-5 INSPECTION CHECK - DW30427LVR

DURA

7/8 14 SPECIAL THREAD PLUG GAGE .875 .8750 NO GO ONLY P.D. = .8350 INSPECTION - DW30426LVR

PENNOYER DODGE

2 1/2 18 NS 3B THREAD PLUG GAGE 2.5 2.50 2.500 NO GO ONLY P.D. = 2.4690 UNS-3B - DW30425LVR

SCHRILLO

3/4 16 UNF STI HELICOIL THREAD PLUG GAGE .75 .750 GO ONLY P.D. = .7906 2B OR 3B - DW30423LVR

CRITERION

1 1/2 18 THREAD PLUG GAGE 1.5 1.50 1.500 1.5000 1 1/2-18 GO ONLY INSPECTION - DW30422LVR

19/32 24 THREAD PLUG GAGE .5937 GO NO GO P.D.'S = .5667 & .5693 INSPECTION CHECK - DW30421LVR

1 1/8 20 N THREAD RING GAGE 1.125 1.1250 UN 1 1/8"-20 GO ONLY INSPECTION CHECK - DW30420LVR

1/2 20 NF 3 BEFORE PLATING THREAD RING GAGE .5 .50 NO GO ONLY P.D. = .4641 UNF-3 - DW30419LVR

1/8 27 NPSF L1 PIPE THREAD PLUG GAGE .125 .1250 2B 1/8"-27 INSPECTION CHECK - DW30417LVR

VERMONT GAGE

BUDGET M8 X 1 6H VERMONT THREAD PLUG GAGE 8 1.0 GO NO GO P.D.'S = 7.350 & 7.500 - DW30416LVR

GTD

3/4 14 NPTF L1 & L3 PIPE THREAD PLUG GAGE .75 .750 .7500 N.P.T.F. DRYSEAL TAPER - DW30415LVR
