Thread Gages

ALAMEDA

3 7/8 16 UN 2A SET THREAD PLUG GAGE 3.875 GO NO GO P.D.'S = 3.8326 & 3.8267 - DW30313LVR

3 1/2 28 UNS 2A SPECIAL SET THREAD PLUG GAGE 3.5 GO NO GO PD'S = 3.4728 & 3.4669 - DW30312BG4

ALAMEDA

3 5/8 28 UNS 2B THREAD PLUG GAGE 3.625 3.6250 GO NO GO P.D.'S = 3.6018 & 3.6080 - DW30311BG4

GSG

4" 16 UN 2B THREAD PLUG GAGE 4.0 4.00 4.000 GO NO GO P.D.'S = 3.9594 & 3.9670 - DW30310BG4

PENNOYER DODGE

1" 11 1/2 ANPT L2 PIPE THREAD RING GAGE 1.0 1.00 1.000 1.0000 A.N.P.T. NPT CHECK - DW30308LVR

1" 11 1/2 ANPT 6 STEP PIPE THREAD RING GAGE 1.0 1.00 1.000 1.0000 A.N.P.T. NPT - DW30307LVR

RUTLAND

NEW 7/8 14 UNF 2A THREAD RING GAGES .875 .8750 GO NO GO P.D.'S = .8270 & .8216 - DW30306BG4

VERMONT GAGE

9/16 24 UNEF 2A SPECIAL VERMONT THREAD RING GAGES .5625 GO NO GO = .5320 & .5280 - DW30305LVR

HEMCO

CERTIFIED 1 1/16 20 UN 2A SET THREAD PLUG GAGE 1.0625 GO NO GO = 1.0286 1.0241 - DW30304TLC

ALAMEDA

1 7/8 40 UNS 2A SET THREAD PLUG GAGE 1.875 GO NO GO P.D.'S = 1.8577 & 1.8539 - DW30303BG4

HILCO

CERTIFIED 2 1/4 12 UN 2A SET THREAD PLUG GAGE 2.25 NO GO ONLY P.D. = 2.1880 - DW30302TLC

CERTIFIED 2 1/4 12 UNF 2A SET THREAD PLUG GAGE 2.25 2.250 GO ONLY P.D. = 2.1941 - DW30301TLC
