Thread Gages

VAN KEUREN

0 80 UNF 2A LEFT HAND THREAD RING GAGE #0 .060 .0600 GO ONLY P.D. = .0514 L.H. - DW31749CC4

GODWIN

10 36 UNS 2A PREPLATE THREAD RING GAGE #10 .190 .1900 NO GO ONLY P.D. = .1681 - DW31748CC4

WEST & DODGE

.1970 48 UNS 2A SPECIAL THREAD RING GAGE .197 NO GO ONLY P.D. = .1802 CHECK - DW31747CC4

8 32 NC 2A MODIFIED THREAD RING GAGE #8 .164 .1640 GO ONLY P.D. = .1420 UNC - DW31746CC4

MERCURY GAGE

10 36 UNS 2A THREAD RING GAGE #10 .190 .1900 NO GO ONLY P.D. = .1681 INSPECTION - DW31744CC4

SCC

M3.5 X .6 6g METRIC THREAD RING GAGE 3.5 0.6 GO ONLY P.D. = 3.088 mm (.1216") - DW31743CC4

ALAMEDA

.197 48 NS 2A THREAD RING GAGE .1970 GO ONLY P.D. = .1828 .197"-48 INSPECTION - DW31742CC4

SCC

M6 X 1 6g METRIC THREAD RING GAGE 6 1.0 NO GO ONLY P.D. = 5.212 mm (.2052") - DW31741CC4

THREDCO

7 1/8 16 UNS 2A THREAD RING GAGES 7.125 7.1250 GO NO GO P.D.'S = 7.0825 & 7.0760 - DW31740OB4

ACCU-GAGE

M3 X .5 7H METRIC THREAD PLUG GAGE 3 0.5 GO NO GO P.D.'S = 2.675 & 2.800 - DW31730OB4

ALAMEDA

1/4 36 UNS BEFORE PLATE THREAD PLUG GAGE .25 GO NO GO P.D.'S = .2340 & .2372 - DW31739CA4

GTD

1/4 36 UNS 2A SET THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .2311 & .2280 - DW31738CA4
