Thread Gages

VERMONT GAGE

M50 X 1.5 6g VERMONT THREAD RING GAGES 50 GO NO GO P.D.'S = 48.994 & 48.834 - DW29414BC4

GTD

1/4 20 NC THREAD RING GAGE .25 .250 .2500 NO GO ONLY P.D. = .2191 UNC CHECK - DW29412LVR

SPI

M12 X 1.25 6g METRIC SOLID THREAD RING GAGE 12 NO GO ONLY P.D. = 11.028 CHECK - DW29410LVR

VERMONT GAGE

M30 X 1 6g LEFT HAND VERMONT THREAD RING GAGES 30 1.0 GO NO GO = 29.324 & 29.199 - DW29408BC4

VERMONT GAGE

M30 X 1 6g VERMONT THREAD RING GAGES 30 1.0 GO NO GO P.D.'S = 29.324 & 29.199 - DW29407BC4

NORTHERN GAUGE

M27 X 1 6g SOLID LEFT HAND THREAD RING GAGES 27 1.0 GO NO GO = 26.324 & 26.199 - DW29406BC4

NORTHERN GAUGE

M22.25 X 2.5 6g SOLID THREAD RING GAGES 22.25 GO NO GO P.D.'S = 20.584 & 20.414 - DW29405BC4

NORTHERN GAUGE

M39 X 3 6g SOLID THREAD RING GAGES 39 3.0 GO NO GO P.D.'S = 37.003 & 36.803 - DW29403BC4

NORTHERN GAUGE

M36 X 3 6g SOLID THREAD RING GAGES 36 3.0 GO NO GO P.D.'S = 34.003 & 33.803 - DW29402BC4

NORTHERN GAUGE

M52 X 4 6g SOLID THREAD RING GAGES 52 4.0 GO NO GO P.D.'S = 49.342 & 49.106 - DW29401BC4

M7 X .5 6h SET THREAD PLUG GAGE 7 0.5 GO ONLY P.D. = .2628 INSPECTION 6.675 mm - DW29400LVR

5/16 24 CL 3 LEFT HAND THREAD PLUG GAGE .3125 GO ONLY P.D. = .2854 L.H. 2B OR 3B - DW29399LVR
