Thread Gages

1/4 36 UNS 3B THREAD PLUG GAGE .25 .250 .2500 GO NO GO P.D.'S = .2320 & .2350 - DW31756CC4

SWANSON

NEW 10 64 UNS THREAD PLUG GAGE #10 .190 .1900 GO ONLY P.D. = .1799 2B OR 3B - DW31755CC4

MERCURY

NEW 9/32 40 UNS 2B THREAD PLUG GAGE .2812 GO ONLY P.D. = .2650 2B OR 3B CHECK - DW31754CC4

S.G. CO.

1/2 20 UNJF 3A THREAD RING GAGES .5 .50 .500 GO NO GO P.D.'S = .4675 & .4643 - DW31753LVR

3/8 16 NS SPECIAL THREAD RING GAGE .375 .3750 GO ONLY P.D. = .3405 INSPECTION - DW31752LVR

ALAMEDA

1/2 20 UNJF 3A THREAD RING GAGES .5 .50 .500 GO NO GO P.D.'S = .4675 & .4643 - DW31751LVR

DEKALB

1" 20 UNS 2A SPECIAL THREAD RING GAGES 1.0 GO NO GO P.D.'S = .9651 & .9611 UNEFS - DW31750LVR

VAN KEUREN

0 80 UNF 2A LEFT HAND THREAD RING GAGE #0 .060 .0600 GO ONLY P.D. = .0514 L.H. - DW31749CC4

GODWIN

10 36 UNS 2A PREPLATE THREAD RING GAGE #10 .190 .1900 NO GO ONLY P.D. = .1681 - DW31748CC4

WEST & DODGE

.1970 48 UNS 2A SPECIAL THREAD RING GAGE .197 NO GO ONLY P.D. = .1802 CHECK - DW31747CC4

8 32 NC 2A MODIFIED THREAD RING GAGE #8 .164 .1640 GO ONLY P.D. = .1420 UNC - DW31746CC4

MERCURY GAGE

10 36 UNS 2A THREAD RING GAGE #10 .190 .1900 NO GO ONLY P.D. = .1681 INSPECTION - DW31744CC4
