Thread Gages

REGAL BELOIT

2" 12 UN 2B LEFT HAND THREAD PLUG GAGE 2.0 GO NO GO P.D.'S = 1.9459 & 1.9538 - DW28602BB4

2 1/4 16 UN 2B OVERSIZE THREAD PLUG GAGE 2.25 GO NO GO P.D.'S = 2.2114 & 2.2176 - DW28592AZ4

LINCOLN GAGE

CERTIFIED M2 X .4 6g SET THREAD PLUG GAGE 2 0.4 GO NO GO P.D.'S = 1.721 & 1.654 - DW28583TLC

VERMONT GAGE

M22 X 2.5 6g VERMONT THREAD RING GAGES 22 GO NO GO P.D.'S = 20.334 & 20.164 - DW28582AZ4

VERMONT

CERTIFIED 1 5/8 16 UN 3A VERMONT THREAD RING GAGES 1.625 GO NOGO = 1.5844 1.5805 - DW28581TLC

PRATT & WHITNEY

CERTIFIED 1 5/8 16 UN 3A THREAD RING GAGES 1.625 GO NO GO PDS= 1.5844 & 1.5805 - DW28580TLC

VAN KEUREN

MJ6 X 1 4h5h METRIC THREAD RING GAGES 6 1.0 GO NO GO P.D.'S = 5.350 & 5.279 - DW28588AZ4

THREAD CHECK

7/8 32 UN 2A THREAD RING GAGES .875 .8750 GO NO GO P.D.'S = .8536 & .8499 CHECK - DW28591AZ4

MJ8 X 1 4h6h METRIC THREAD RING GAGES 8 1.0 GO NO GO P.D.'S = 7.350 & 7.279 - DW28573AZ4

NEW CERTIFIED M36 X 1.5 6H THREAD PLUG GAGE 36 GO NO GO PD'S = 35.026 & 35.226 - DW28578TLC

VK

1" 20 UNJEF 3B THREAD PLUG GAGE 1.0 1.00 1.000 GO NO GO P.D.'S = .9675 & .9719 - DW28590AZ4

ATLAS

CERTIFIED 11/16 20 UN 2A SET THREAD PLUG GAGE .6875 GO NO GO PDS= .6537 & .6494 - DW28587TLC
