Thread Gages

ACCU-GAGE

1/2 32 UNS 2A BEFORE PLATE THREAD RING GAGE .5 .50 .500 GO ONLY P.D. = .4757 - DW31562BZ4

GTD

1 1/2 11 1/2 NPT L1 PIPE THREAD RING GAGE 1.5 1.50 1.500 1.5000 N.P.T. NATIONAL - DW31561BZ4

VERMONT GAGE

1 1/2 16 UN 2A VERMONT THREAD RING GAGES 1.5 GO NO GO P.D.'S = 1.4578 & 1.4526 - DW31560BZ4

VERMONT GAGE

13/16 16 UN 3B SPECIAL VERMONT THREAD PLUG GAGE .8125 GO ONLY P.D. = .7755 - DW31559BY4

VERMONT GAGE

13/16 16 UN 3B SPECIAL VERMONT THREAD PLUG GAGE .8125 GO ONLY P.D. = .7739 - DW31558BY4

VERMONT GAGE

13/16 16 UN 3B SPECIAL VERMONT THREAD PLUG GAGE .8125 NO GO ONLY P.D. = .7776 - DW31557BY4

NEW 1 1/2 6 UNC 2A SOLID THREAD RING GAGES 1.5 GO NO GO P.D.'S = 1.3893 & 1.3812 - DW31580MSAF

NEW 11/16 28 UN 2A SOLID THREAD RING GAGES .6875 GO NO GO P.D.'S = .6632 & .6594 - DW31579MSAF

NEW 1 1/16 18 UNEF 2A SOLID THREAD RING GAGES 1.0625 GO NO GO = 1.0250 & 1.0203 - DW31578MSAF

NEW 1 5/16 20 UN 2A SOLID THREAD RING GAGES 1.3125 GO NO GO PDS= 1.2786 & 1.2739 - DW31577MSAF

NEW M56 X 4 6H METRIC THREAD PLUG GAGE 56 4.0 GO NO GO P.D.'S = 53.402 & 53.717 - DW31576MSAF

CERTIFIED M14 X 1.5 6g SET THREAD PLUG GAGE 14 GO NO GO PD'S = 12.994 & 12.854 - DW31555TLC
