.1970 48 UNS 2A SPECIAL THREAD RING GAGE .197 NO GO ONLY P.D. = .1802 CHECK - DW31747CC4

8 32 NC 2A MODIFIED THREAD RING GAGE #8 .164 .1640 GO ONLY P.D. = .1420 UNC - DW31746CC4

MERCURY GAGE

10 36 UNS 2A THREAD RING GAGE #10 .190 .1900 NO GO ONLY P.D. = .1681 INSPECTION - DW31744CC4

SCC

M3.5 X .6 6g METRIC THREAD RING GAGE 3.5 0.6 GO ONLY P.D. = 3.088 mm (.1216") - DW31743CC4

ALAMEDA

.197 48 NS 2A THREAD RING GAGE .1970 GO ONLY P.D. = .1828 .197"-48 INSPECTION - DW31742CC4

SCC

M6 X 1 6g METRIC THREAD RING GAGE 6 1.0 NO GO ONLY P.D. = 5.212 mm (.2052") - DW31741CC4

ACCU-GAGE

M3 X .5 7H METRIC THREAD PLUG GAGE 3 0.5 GO NO GO P.D.'S = 2.675 & 2.800 - DW31730OB4

ALAMEDA

1/4 36 UNS BEFORE PLATE THREAD PLUG GAGE .25 GO NO GO P.D.'S = .2340 & .2372 - DW31739CA4

GTD

1/4 36 UNS 2A SET THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .2311 & .2280 - DW31738CA4

ACCU-GAGE

1/4 20 UNC 1B LEFT HAND THREAD PLUG GAGE .25 GO NO GO P.D.'S = .2175 & .2248 - DW31728OB4

SOSSNER

15/32 32 NS 2 THREAD PLUG GAGE .4687 GO NO GO P.D.'S = .4485 & .4521 INSPECTION - DW31737CA4

GSG

M3.5 X .8 6G METRIC WORK THREAD PLUG GAGE 3.5 0.8 GO NO GO PD'S = 3.004 & 3.129 - DW31727OB4
