Thread Gages

HELI-COIL

5/16 18 UNC 2B STI HELICOIL THREAD PLUG GAGE .3125 NO GO ONLY P.D. = .3529 CHECK - DW27383AM4

HELI-COIL

7/16 14 UNC 2B STI HELICOIL THREAD PLUG GAGE .4375 GO NO GO PD'S = .4839 & .4890 - DW27381AM4

SHOP MADE 7 3/8 12 THREAD PLUG GAGE 7.375 7.3750 7 3/8"-12 INSPECTION CHECK - DW27377RD

SHOP MADE 7.066 8 ALUMINUM AN36 LOCKNUT THREAD PLUG GAGE 7.066"-8 INSPECTION - DW27376RD

SHOP MADE 1 1/4 18 THREAD PLUG GAGE 1.25 1.250 1.2500 GO ONLY P.D. = 1.21238 - DW27370RD

SHOP MADE 1 3/4 2 1/2 ACME THREAD PLUG GAGE 1.75 2.5 GO NO GO = 1.5503 & 1.5632 - DW27369RD

SHOP MADE 1 3/4 2 1/2 ACME LEFT HAND THREAD PLUG GAGE 1.75 GO NOGO 1.5501 1.5624 - DW27368RD

SHOP MADE 7.370 6 ACME THREAD PLUG GAGE 7.37 7.3700 7.370"-6 INSPECTION CHECK - DW27380RD

SHOP MADE 3 5/8 16 UN 2B THREAD PLUG GAGE 3.625 3 5/8"-16 INSPECTION CHECK - DW27367RD

SHOP MADE 8" 8 THREAD PLUG GAGE 8.0 8.00 8.000 8.0000 8"-8 INSPECTION CHECK - DW27379RD

SHOP MADE 4" 12 THREAD PLUG GAGE 4.0 4.00 4.000 4.0000 4"-12 INSPECTION CHECK - DW27366RD

BUDGET SHOP MADE M76 X 1.5 THREAD PLUG GAGE 76 METRIC GO AND NO GO INSPECTION - DW27374LVR
