Thread Gages

VERMONT GAGE

M9 X .75 6H VERMONT THREAD PLUG GAGE 9 0.75 GO NO GO P.D.'S = 8.513 & 8.645 - DW31586BZ4

VERMONT GAGE

1 3/16 12 UN 3B VERMONT THREAD PLUG GAGE 1.1875 GO NO GO PD'S = 1.1334 & 1.1390 - DW31585BZ4

VERMONT GAGE

1 3/16 28 UN 3B VERMONT THREAD PLUG GAGE 1.1875 GO NO GO PD'S = 1.1643 & 1.1683 - DW31584BZ4

SHOP MADE .206 36 THREAD PLUG GAGE .2060 GO NO GO P.D.'S = .190 & .192 CHECK - DW31583BZ4

SCC

1 3/8 12 UNF 2A THREAD RING GAGE 1.375 1.3750 GO ONLY P.D. = 1.3190 INSPECTION - DW31582LVR

ACCU GAGE

2.355 36 UNS 2B THREAD PLUG GAGE 2.3550 GO NO GO P.D.'S = 2.3370 & 2.3423 CHECK - DW31581BZ4

LINCOLN GAGE

15/16 16 NS LEFT HAND THREAD RING GAGE .9375 NO GO ONLY P.D. = .9000 L.H. CHECK - DW31171BX4

ALAMEDA

9/16 24 UNEF 3A THREAD RING GAGE .5625 GO ONLY P.D. = .5354 INSPECTION CHECK - DW31169BX4

ALAMEDA

11/16 24 NEF SPECIAL THREAD RING GAGE .6875 NO GO ONLY P.D. = .6529 UNEF CHECK - DW31168BX4

JOHNSON

1/2 14 ACME 4C THREAD RING GAGE .5 .50 .500 .5000 GO ONLY P.D. = .4615 CHECK - DW31167BX4

SCHRILLO

CERTIFIED 3 11/16 12 UNS 3A SET THREAD PLUG GAGE 3.6875 GO NO GO = 3.6334 3.6286 - DW31166TLC

1" 32 NS 2A THREAD RING GAGE 1.0 1.00 1.000 NO GO ONLY P.D. = .9748 UNS-2A CHECK - DW31165BX4
