Thread Gages

ALAMEDA

CERTIFIED 10 24 UNC 2A THREAD RING GAGES #10 .190 GO NO GO PD'S = .1619 & .1586 - DW31535TLC

PONAM

CERTIFIED 4 40 UNC 2A THREAD RING GAGES #4 .112 GO NO GO P.D.'S = .0950 & .0925 - DW31534TLC

CERTIFIED 0 80 UNF 2A THREAD RING GAGES #0 .060 GO NO GO P.D.'S = .0514 & .0496 - DW31533TLC

CERTIFIED 6 32 UNC 2A THREAD RING GAGES #6 .138 GO NO GO P.D.'S = .1169 & .1141 - DW31532TLC

CERTIFIED 6 40 UNF 2A THREAD RING GAGES #6 .138 GO NO GO P.D.'S = .1210 & .1184 - DW31531TLC

CERTIFIED 8 32 UNC 2A THREAD RING GAGES #8 .164 GO NO GO P.D.'S = .1428 & .1399 - DW31530TLC

CERTIFIED 10 32 UNF 3A THREAD RING GAGES #10 .190 GO NO GO PD'S = .1697 & .1674 - DW31529TLC

VERMONT GAGE

CERTIFIED M20 X 1.5 6g VERMONT THREAD RING GAGES 20 GO NO GO = 18.994 & 18.854 - DW31528TLC

CERTIFIED 4 48 UNF 2A THREAD RING GAGES #4 .112 GO NO GO P.D.'S = .0978 & .0954 - DW31527TLC

CERTIFIED 5 40 UNC 2A THREAD RING GAGES #5 .125 GO NO GO P.D.'S = .1080 & .1054 - DW31526TLC

CERTIFIED 6 32 UNC 3A THREAD RING GAGES #6 .138 GO NO GO P.D.'S = .1177 & .1156 - DW31525TLC

VERMONT GAGE

5/8 18 UNJF 3A VERMONT THREAD RING GAGES .625 GO NO GO P.D.'S = .5889 & .5854 - DW31524BZ4
