Thread Gages

TAFT PEIRCE

3/4 10 NC 5 THREAD RING GAGE .75 .750 .7500 GO ONLY P.D. = .6856 UNC-5 3A CHECK - DW31883CB4

TAFT PEIRCE

5/8 11 NC 5 THREAD RING GAGE .625 .6250 NO GO ONLY P.D. = .5689 UNC-5 CHECK - DW31882CB4

TAFT PEIRCE

5/8 18 NF 5 THREAD RING GAGE .625 .6250 GO ONLY P.D. = .5944 UNF-5 3A CHECK - DW31881CB4

TRW

10 64 UNS 2B THREAD PLUG GAGE #10 .190 .1900 GO NO GO P.D.'S = .1799 & .1830 - DW31880CC4

EFCO

10 64 NS 2B THREAD PLUG GAGE #10 .190 .1900 NO GO ONLY P.D. = .1830 UNS-2B CHECK - DW31879CC4

SOSSNER

11/16 27 NS 1 THREAD PLUG GAGE .6875 GO NO GO P.D.'S = .6634 & .6691 INSPECTION - DW31878CC4

2 56 UNC 2B STI HELICOIL THREAD PLUG GAGE #2 .086 .0860 NO GO ONLY P.D. = .0996 - DW31877CC4

GTD

4 36 NS 2B THREAD PLUG GAGE #4 .112 .1120 GO NO GO P.D.'S = .0940 & .0979 UNS-2B - DW31876CC4

PRATT & WHITNEY

1/4 40 NS 2 THREAD PLUG GAGE .25 .250 .2500 GO NO GO P.D.'S = .2338 & .2365 - DW31875CC4

GODWIN

.473 60 NS 3 THREAD PLUG GAGE .4730 GO NO GO P.D.'S = .4622 & .4637 INSPECTION - DW31874CC4

TRW

6 24 UNS 2B THREAD PLUG GAGE #6 .138 .1380 GO NO GO P.D.'S = .1109 & .1150 - DW31873CC4

VERMONT

1/4 36 UNS 2B VERMONT THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .2320 & .2360 - DW31872CC4
