Thread Gages

SHOP MADE 5/8 12 SOLID THREAD RING GAGE .625 .6250 5/8"-12 INSPECTION CHECK - DW30801LVR

BATH

1/2 20 NF 2 LEFT HAND THREAD RING GAGE .5 .50 GO ONLY P.D. = .4675 UNF-2 3A L.H. - DW30800LVR

PRATT & WHITNEY

5/8 11 US STD EXTRA THICK LEFT HAND THREAD RING GAGE .625 .6250 L.H. GO ONLY - DW30799LVR

GTD

7/16 14 NC 2 LEFT HAND THREAD RING GAGE .4375 GO ONLY P.D. = .3911 UNC-2 3A L.H. - DW30798LVR

PRATT & WHITNEY

3/4 10 US STD LEFT HAND THREAD RING GAGE .75 .750 .7500 L.H. GO ONLY INSPECTION - DW30797LVR

SHOP MADE 1" 12 LEFT HAND SOLID THREAD RING GAGE 1.0 1.00 1.000 1.0000 L.H. - DW30796LVR

PRATT & WHITNEY

1 5/16 16 N 3 THREAD PLUG GAGE 1.3125 GO NO GO P.D.'S = 1.2719 & 1.2758 UN-3 - DW30795LVR

3/8 14 AB THREAD RING GAGE .375 .3750 3/8"-14 GO ONLY INSPECTION CHECK - DW30794LVR

SHOP MADE 2 3/4 8 CLASS 3 ALUMINUM THREAD PLUG GAGE 2.75 2.750 GO AND NO GO - DW30793BL4

BOICE

.933 40 NS 3 SET THREAD PLUG GAGE .9330 GO NO GO P.D.'S = .9168 & .9135 CHECK - DW30792BK4

PENNOYER DODGE

CERTIFIED 1 3/8 12 UNF 2A SET THREAD PLUG GAGE 1.375 GO ONLY PD = 1.3190 CHECK - DW30791TLC

SHOP MADE 1 1/2 8 UNC 3B THREAD PLUG GAGE 1.5 1.50 1.500 GO AND NO GO CHECK - DW30790BK4
