Thread Gages

ALAMEDA

2 56 UNS BEFORE PLATE THREAD PLUG GAGE #2 .086 GO NO GO P.D.'S = .0764 & .0784 - DW31810CA4

9/32 40 UNS 2B PREPLATE THREAD PLUG GAGE .2812 GO NO GO P.D.'S = .2660 & .2698 - DW31809CA4

PRATT & WHITNEY

2 64 UNF 3A SET THREAD PLUG GAGE #2 .086 .0860 GO NO GO P.D.'S = .0759 & .0744 - DW31808CA4

ALAMEDA

1/4 36 UNS BEFORE PLATE THREAD PLUG GAGE .25 GO NO GO P.D.'S = .2344 & .2376 - DW31807CA4

REGAL BELOIT

CERTIFIED 1 5/8 16 UN 3A SET THREAD PLUG GAGE 1.625 GO ONLY P.D. = 1.5844 CHECK - DW31806TLC

GTD

CERTIFIED 1 5/8 12 NS SET THREAD PLUG GAGE 1.625 GO NO GO PDS= 1.5699 & 1.5665 - DW31805TLC

REGAL BELOIT

CERTIFIED M10 X 1.5 6g SET THREAD PLUG GAGE 10 GO NO GO P.D.'S = 8.994 & 8.862 - DW31804TLC

PONAM

3/8 36 UNS 2B LEFT HAND EXTRA LONG THREAD PLUG GAGE .375 GO NO GO = .3570 .3612 - DW31802CA4

VAN KEUREN

1/4 40 UNS 2A SET THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .2329 & .2300 NS - DW31801CA4

MERCURY

3 1/4 16 UN 2A THREAD RING GAGES 3.25 3.250 GO NO GO P.D.'S = 3.2077 & 3.2021 - DW31800OB4

MERCURY

3 1/4 12 UNC 2A THREAD RING GAGES 3.25 GO NO GO P.D.'S = 3.1940 & 3.1877 UNS - DW31799OB4

MERCURY

3 1/4 16 UN 2A SET THREAD PLUG GAGE 3.25 3.250 GO NO GO P.D.'S = 3.2077 & 3.2021 - DW31798OB4
