Pipe Plug Gages

NORTH AMERICAN

1/8 27 NPSM PIPE THREAD PLUG GAGE .125 .1250 GO NO GO P.D.'S = .3736 & .3783 2B - DW31888CB4

ALAMEDA

1/16 27 NPT L1 PIPE THREAD PLUG GAGE .0625 N.P.T. NATIONAL TAPER INSPECTION - DW31645LVR

BUDGET G1" 11 BSPP PIPE THREAD PLUG GAGE 1.0 GO NO GO P.D.'S = 31.770 & 31.950 - DW31643LVR

G3/4 14 BSPP PIPE THREAD PLUG GAGE .75 .750 GO NO GO P.D.'S = 25.279 & 25.421 - DW31569LVR

SPI

1/16 27 NPT L1 PIPE THREAD PLUG GAGE .0625 N.P.T. NATIONAL TAPER INSPECTION - DW31565LVR

GODWIN

1/16 27 NPT L1 PIPE THREAD PLUG GAGE .0625 N.P.T. NATIONAL TAPER INSPECTION - DW31563LVR

VERMONT GAGE

NEW 3/8 18 NGT L1 & L9 VERMONT PIPE THREAD PLUG GAGE .375 NATIONAL GAS TAPER - DW31511BY4

NEW 1/2 14 NPT L1 PIPE THREAD PLUG GAGE .5 .50 .500 .5000 NATIONAL TAPER 3 STEP - DW31293MSAF

NEW G2" 11 BSPP PIPE THREAD PLUG GAGE 2.0 GO NO GO P.D.'S = 58.135 & 58.315 - DW31292MSAF

NEW G2 1/2 11 BSPP PIPE THREAD PLUG GAGE 2.5 GO NO GO P.D.'S = 73.705 & 73.922 - DW31291MSAF

NEW G 5/8 14 BSPP PIPE THREAD PLUG GAGE .625 GO NO GO PDS = 21.749 & 21.891 G5/8 - DW31288MSAF

NEW 1" 11 1/2 NPSM PIPE THREAD PLUG GAGE 1.0 GO NO GO PD'S = 1.2386 & 1.2462 2B - DW31287MSAF
