Pipe Plug Gages

ATLAS

1" 11 1/2 NPT L1 PIPE THREAD RING GAGE 1.0 1.00 1.000 1.0000 N.P.T. NATIONAL - DW28432BA4

2" 11 1/2 NPT L3 PIPE THREAD PLUG GAGE 2.0 2.00 2.000 2.0000 N.P.T. ANPT - DW28286AX4

1 1/2 11 1/2 NPT L3 PIPE THREAD PLUG GAGE 1.5 1.50 1.500 1.5000 N.P.T. ANPT - DW28285AX4

GTD

5" 8 NPT L1 PIPE THREAD PLUG GAGE 5.0 5.00 5.000 5.0000 N.P.T. NATIONAL TAPER - DW28199AX4

PONAM

2" 11 1/2 NPSM PIPE THREAD PLUG GAGE 2.0 GO NO GO P.D.'S = 2.2963 & 2.3044 2B - DW28143AX4

PRATT & WHITNEY

3 1/2 8 NPT L1 PIPE THREAD PLUG GAGE 3.5 3.50 3.500 3.5000 N.P.T. NATIONAL TAPER - DW28154AX4

NEW 3 1/2 8 NPT L1 PIPE THREAD PLUG GAGE 3.5 3.50-8 N.P.T. L-1 TAPER INSPECTION - MS6526MJ

REGAL PREMIUM

1/2 14 NPSI PIPE THREAD PLUG GAGE .5 .50 .500 GO NO GO P.D.'S = .7745 & .7812 2B - DW28031RD

MERCURY GAGE

1 1/4 11 1/2 NPTF L1 PIPE THREAD PLUG GAGE 1.25 1.250 1.2500 N.P.T.F. DRYSEAL - DW27969RD

PENNOYER DODGE

3/8 18 ANPT L3 PIPE THREAD PLUG GAGE .375 .3750 A.N.P.T. AERONAUTICAL TAPER NPT - DW27899LVR

BESLY

3/8 18 NPTF L3 & 6 STEP PIPE THREAD PLUG GAGE .375 .3750 N.P.T.F. DRYSEAL TAPER - DW27859RD

SHEFFIELD

1/8 27 ANPT NON-THREADED REFERENCE PIPE THREAD PLUG GAGE .125 .1250 CREST SET - DW27839RD
