Pipe Plug Gages

1" 11 1/2 ANPT 6 STEP PIPE THREAD PLUG GAGE 1.0 1.00 1.000 A.N.P.T. CREST CHECK - DW27550AQ4

WIDELL

1/8 27 NPSM 2B PIPE THREAD PLUG GAGE .125 .1250 GO NO GO P.D.'S = .3726 & .3783 - DW27545AQ4

1/4 19 BSPP PIPE THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .4843 & .4892 G1/4 - DW27548AQ4

REGAL PREMIUM

3/4 14 BSPT 55 DEGREE MOD PIPE THREAD PLUG GAGE .75 .750 BRITISH TAPER Rc3/4 - DW27551AQ4

SCHRILLO

1/4 18 ANPT L1 3 STEP & L3 PIPE THREAD PLUG GAGE .25 .250 .2500 A.N.P.T. - DW27512RD

1/8 27 NPTF L3 & 6 STEP PIPE THREAD PLUG GAGE .125 .1250 N.P.T.F. DRYSEAL TAPER - DW27487AQ4

PRATT & WHITNEY

1/4 18 NPTF 6 STEP PIPE THREAD PLUG GAGE .25 .250 .2500 N.P.T.F. DRYSEAL TAPER - DW27493AQ4

1 1/2 11 BSPP PIPE THREAD PLUG GAGE 1.5 GO NOGO PDS= 46.324 & 46.504 MOD. G1 1/2 - DW27245AS4

GSG

3/4 14 NPT 6 STEP PIPE THREAD PLUG GAGE .75 .750 .7500 N.P.T. ANPT CREST CHECK - DW27191AP4

R 1/2 14 BSPT SYS. B PIPE THREAD PLUG GAGE .5 .50 .500 .5000 BRITISH TAPER R1/2 - DW27139AP4

GTD

3/4 14 NPT L3 & 6 STEP PIPE THREAD PLUG GAGE .75 .750 .7500 N.P.T. NATIONAL ANPT - DW27138AP4

1/8 27 NPT SPECIAL PIPE THREAD PLUG GAGE .125 .1250 N.P.T. NATIONAL TAPER - DW27130AP4
