Pipe Plug Gages

GSG

1 1/2 11 1/2 NPT L1 & L3 PIPE THREAD PLUG GAGE 1.5 1.50 1.500 1.5000 N.P.T. ANPT - DW27132AP4

THREADCHECK

1" 11 1/2 NPSF PIPE THREAD PLUG GAGE 1.0 GO NO GO P.D.'S = 1.2284 & 1.2365 2B - DW27077AJ4

ALAMEDA

2 3/8 8 EXT UPSET TUBING API PIPE THREAD PLUG GAGE 2.375 2 3/8"-8 EUE UP TBG - DW27049AJ4

SHOP MADE 1 1/2 11 1/2 NPS PIPE THREAD PLUG GAGE 1.5 1.50 1.500 1.5000 CHECK - DW27019AJ4

THREADCHECK

1" 11 1/2 NPT L1 LEFT HAND PIPE THREAD PLUG GAGE 1.0 1.00 1.000 L.H. N.P.T. - DW26975AJ4

BENDIX

1/16 27 NPSF PIPE THREAD PLUG GAGE .0625 GO NO GO P.D.'S = .2756 & .2803 2B - DW26048BL3

DETROIT

1/8 27 NPSF PIPE THREAD PLUG GAGE .125 .1250 GO NO GO P.D.'S = .3680 & .3727 2B - DW26047BL3

WEDIN

3/4 14 NPSI L1 PIPE THREAD PLUG GAGE .75 .750 .7500 3/4"-14 INSPECTION CHECK - DW26046BL3

DETROIT

1/16 27 NPSF PIPE THREAD PLUG GAGE .0625 GO ONLY P.D. = .2756 INSPECTION 2B - DW26043BL3

DETROIT

3/8 18 NPSF PIPE THREAD PLUG GAGE .375 .3750 GO NO GO P.D.'S = .6196 & .6244 2B - DW26051BL3

WEDIN

3/8 18 NPSF PIPE THREAD PLUG GAGE .375 .3750 GO NO GO P.D.'S = .6196 & .6244 2B - DW26053BL3

G.A. CO.

1/8 27 NPSF MODIFIED PIPE THREAD PLUG GAGE .125 GO NO GO PD'S = .3680 & .3727 2B - DW26050BL3
