Set Plug Gages for Calibrating Ring Gages

PRATT & WHITNEY

1 1/8 16 N 3 SET THREAD PLUG GAGE 1.125 1.1250 GO NO GO P.D.'S = 1.0844 & 1.0806 - DW31898LVR

TAFT PEIRCE

3/8 24 NF 5 SET THREAD PLUG GAGE .375 .3750 GO NO GO P.D.'S = .3523 & .3497 - DW31886CB4

CERTIFIED 4 1/2 12 UN 3A SET THREAD PLUG GAGE 4.5 4.50 GO ONLY P.D. = 4.4459 - DW31840TLC

ALLEN

CERTIFIED 3 1/2 12 UN 2A SET THREAD PLUG GAGE 3.5 3.50 GO ONLY P.D. = 3.4440 - DW31819TLC

PRATT & WHITNEY

2 64 UNF 3A SET THREAD PLUG GAGE #2 .086 .0860 GO NO GO P.D.'S = .0759 & .0744 - DW31808CA4

REGAL BELOIT

CERTIFIED 1 5/8 16 UN 3A SET THREAD PLUG GAGE 1.625 GO ONLY P.D. = 1.5844 CHECK - DW31806TLC

GTD

CERTIFIED 1 5/8 12 NS SET THREAD PLUG GAGE 1.625 GO NO GO PDS= 1.5699 & 1.5665 - DW31805TLC

REGAL BELOIT

CERTIFIED M10 X 1.5 6g SET THREAD PLUG GAGE 10 GO NO GO P.D.'S = 8.994 & 8.862 - DW31804TLC

VAN KEUREN

1/4 40 UNS 2A SET THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .2329 & .2300 NS - DW31801CA4

MERCURY

3 1/4 16 UN 2A SET THREAD PLUG GAGE 3.25 3.250 GO NO GO P.D.'S = 3.2077 & 3.2021 - DW31798OB4

MERCURY

3 1/4 12 UNC 2A SET THREAD PLUG GAGE 3.25 GO NO GO P.D.'S = 3.1940 & 3.1877 - DW31797OB4

GTD

1/4 36 UNS 2A SET THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .2311 & .2280 - DW31738CA4
