Set Plug Gages for Calibrating Ring Gages

M14 X 1 6g METRIC SET THREAD PLUG GAGE 14 1.0 GO NO GO P.D.'S = 13.324 & 13.206 - DW30744BN4

VERMONT GAGE

M16 X 1.5 6g VERMONT SET THREAD PLUG GAGE 16 GO NO GO P.D.'S = 14.994 & 14.854 - DW30742BN4

2" 12 UN 3A SET THREAD PLUG GAGE 2.0 2.00 GO NO GO P.D.'S = 1.9459 & 1.9414 - DW30713BN4

GSG

1 3/4 18 UNS 2A SET THREAD PLUG GAGE 1.75 GO NO GO P.D.'S = 1.7124 & 1.7073 - DW30712BN4

M22 X 1 6g METRIC SET THREAD PLUG GAGE 22 1.0 GO NO GO P.D.'S = 21.324 & 21.206 - DW30707BN4

MERCURY GAGE

5/8 32 UN 2A SET THREAD PLUG GAGE .625 .6250 GO NO GO P.D.'S = .6036 & .6000 - DW30706BN4

M18 X 1 6g METRIC SET THREAD PLUG GAGE 18 1.0 GO NO GO P.D.'S = 17.324 & 17.206 - DW30705BN4

M20 X 2.5 6g METRIC SET THREAD PLUG GAGE 20 GO NO GO P.D.'S = 18.334 & 18.164 - DW30704BN4

GSG

1/2 20 UNF 2A PREPLATE SET THREAD PLUG GAGE .5 GO NO GO P.D.'S = .4642 & .4611 - DW30703BN4

GSG

9/16 18 UNF 2A BEFORE PLATE SET THREAD PLUG GAGE .5625 GO NO GO = .5205 & .5175 - DW30701BN4

VERMONT GAGE

M10 X 1.75 6g VERMONT SET THREAD PLUG GAGE 10 GO NO GO P.D.'S = 8.829 & 8.687 - DW30697BN4

LINCOLN GAGE

9/32 40 SET THREAD PLUG GAGE .2812 GO NO GO P.D.'S = .2650 & .2640 INSPECTION - DW30672BK4
