Set Plug Gages for Calibrating Ring Gages

VERMONT GAGE

1.312 20 UNS 3A LEFT HAND SET THREAD PLUG GAGE 1 5/16 GO NO GO = 1.2795 1.2760 - DW13141AP1

DOALL

1 1/2 18 NEF 3 SET THREAD PLUG GAGE 1.5 1.50 GO NO GO P.D.'S = 1.4639 & 1.4601 - DW13150AP1

PRATT & WHITNEY

3.230 20 NS 1 LEFT HAND SET THREAD PLUG GAGE 3.23 3.2300 GO NO GO P.D.'S = 3.1960 & 3.1858 - DW13156AP1

1" 8 NS 4 SET THREAD PLUG GAGE 1.0 1.00 1.000 GO NO GO P.D.'S = .9253 & .9226 - DW13148AP1

PRATT & WHITNEY

1 1/4 18 NS SET THREAD PLUG GAGE 1.25 1.250 GO NO GO P.D.'S = 1.2139 & 1.2102 - DW13144AP1

1" 8 NC 5 SET THREAD PLUG GAGE 1.0 1.00 1.000 GO NO GO P.D.'S = .9316 & .9262 - DW13146AP1

ACCRA

2.969 16 NS 3A SET THREAD PLUG GAGE 2.9690 GO NO GO P.D.'S = 2.9280 & 2.9240 - DW13157AP1

2 1/8 12 UN 3A SET THREAD PLUG GAGE 2.125 GO NO GO P.D.'S = 2.0709 & 2.0664 - DW13131AP1

DUNDICK

2 1/8 16 UN LEFT HAND SPECIAL SET THREAD PLUG GAGE 2.125 GO NO GO= 2.0790 2.0770 - DW13130AP1

3/4 10 NC 5 SET THREAD PLUG GAGE .75 .750 .7500 GO ONLY P.D. = .6995 INSPECTION - DW13121AP1

3/4 10 UNS SET THREAD PLUG GAGE .75 .750 .7500 NO GO ONLY P.D. = .6915 CHECK - DW13122AP1

3/4 10 NC 5 HF SET THREAD PLUG GAGE .75 .750 GO NO GO P.D.'S = .6955 & .6930 - DW13123AP1
