Set Plug Gages for Calibrating Ring Gages

ALAMEDA

3/8 24 UNJF 3A SET THREAD PLUG GAGE .375 .3750 GO NO GO P.D.'S = .3479 & .3450 - DW31736CA4

PRATT & WHITNEY

6 40 UNF 3A SET THREAD PLUG GAGE #6 .138 .1380 GO NO GO P.D.'S = .1218 & .1198 - DW31722CC4

MERCURY GAGE

CERTIFIED 5/16 20 UN 2A 4 START SET THREAD PLUG GAGE .3125 GO NOGO = .2788 .2748 - DW31720TLC

CERTIFIED 4 1/2 12 UN 3A SET THREAD PLUG GAGE 4.5 4.50 NO GO ONLY P.D. = 4.4410 - DW31679TLC

PONAM

CERTIFIED 1 11/16 8 UN 2A SET THREAD PLUG GAGE 1.6875 GO NO GO = 1.6041 1.5966 - DW31678TLC

CERTIFIED M20 X 2.5 6g SET THREAD PLUG GAGE 20 GO NO GO PD'S = 18.334 & 18.164 - DW31677TLC

1 1/16 20 UN 2A HILO SET THREAD PLUG GAGE 1.0625 GO NO GO PD'S = 1.0286 & 1.0241 - DW31642LVR

BUDGET .336 24 NS 2A SET THREAD PLUG GAGE .3360 GO NO GO P.D.'S = .3078 & .3040 - DW31641LVR

GSG

CERTIFIED 1 3/16 18 UNEF 2A SET THREAD PLUG GAGE 1.1875 GO NO GO = 1.1499 1.1450 - DW31640TLC

PRATT & WHITNEY

1 1/2 27 NS 3 SET THREAD PLUG GAGE 1.5 1.50 GO NO GO P.D.'S = 1.4759 & 1.4719 - DW31600OB4

PRATT & WHITNEY

1 13/16 16 N 2A SET THREAD PLUG GAGE 1.8125 GO NO GO P.D.'S = 1.7703 & 1.7650 - DW31599OB4

P & W

2" 16 UN 2A SET THREAD PLUG GAGE 2.0 2.00 GO NO GO P.D.'S = 1.9578 & 1.9524 - DW31598OB4
