Set Plug Gages for Calibrating Ring Gages

JOHNSON GAGE CO.

11/16 16 UNS 3A TRUNCATED SET THREAD PLUG GAGE .6875 GO ONLY P.D. = .6369 NS-3A

G.A. CO.

12 24 UNC 2A SET THREAD PLUG GAGE #12 .216 GO ONLY P.D. = .1879 NC-2A QUALITY

METRO

7/8 40 UNS 2A SPECIAL SET THREAD PLUG GAGE .875 .8750 NO GO ONLY P.D. = .8547

G.A. CO.

M8 X 1.25 SPECIAL SET THREAD PLUG GAGE 8.0 NO GO ONLY P.D. = 6.992 QUALITY

GAGE ASSEMBLY CO.

M12 X 1.75 SPECIAL SET THREAD PLUG GAGE 12.0 GO ONLY P.D. = 10.734 QUALITY

SCC

9/16 18 UNF 2A BEFORE PLATE SET THREAD PLUG GAGE .5625 GO ONLY P.D.= .5238 NF-2A

5/16 24 NS SET THREAD PLUG GAGE .3125 NO GO ONLY P.D. = .2800 UNS QUALITY TOOL

GAGE ASSEMBLY CO.

9/16 18 UNF 2A SPL SPECIAL SET THREAD PLUG GAGE .5625 GO ONLY P.D. = .5194 TOOL

G.A. CO.

1 5/8 11 1/2 UNS SET THREAD PLUG GAGE 1.625 11.5 GO NO GO PD'S = 1.5667 & 1.5607

1 5/16 14 UNS 2A SET THREAD PLUG GAGE 1.3125 GO NO GO P.D.'S = 1.2645 & 1.2591

GAGE ASSEMBLY CO.

M16 X 1.25 SPECIAL SET THREAD PLUG GAGE 16.0 GO ONLY P.D. = 15.188 M16 x 1.25

M16 X 1.5 6G METRIC SET THREAD PLUG GAGE 16.0 1.50 NO GO ONLY P.D. = 15.248 mm
