Set Plug Gages for Calibrating Ring Gages

PONAM

1 1/4 12 UNF 2A PREPLATE SET THREAD PLUG GAGE 1.25 GO NO GO PDS= 1.1917 & 1.1859

PONAM

7/8 24 UNS 2A BEFORE PLATE SET THREAD PLUG GAGE .875 GO NO GO PDS= .8455 & .8414

1 1/4 10 UNS 2A SET THREAD PLUG GAGE 1.25 GO NO GO P.D.'S = 1.1819 & 1.1764

PONAM

3/4 16 UNF 2A BEFORE PLATE SET THREAD PLUG GAGE .75 GO NO GO PDS = .7034 & .6984

PONAM

7/8 27 UNS 2A BEFORE PLATE SET THREAD PLUG GAGE .875 GO NO GO PDS= .8485 & .8446

PONAM

1 1/2 18 UNEF 2A MODIFIED SET THREAD PLUG GAGE 1.5 GO NO GO PDS= 1.4602 & 1.4555

GTD

1 3/8 16 NS 3 SET THREAD PLUG GAGE 1.375 GO ONLY P.D. = 1.3344 UNS-3 CHECK

3/8 24 UN 2A OVERSIZE SET THREAD PLUG GAGE .375 GO NO GO P.D.'S = .3441 & .3403

SHOP MADE .800 - 10 .1P .2L UNJS 3A SET THREAD PLUG GAGE .8 .80 DOUBLE LEAD 2STR

SWANSON

M33 X 3.5 6g LEFT HAND SET THREAD PLUG GAGE 33.0 GO NO GO PD'S = 30.674 & 30.462

G.A. CO.

6 56 UNS 3A SET THREAD PLUG GAGE #6 .138 GO NO GO P.D.'S = .1264 & .1246 NS-3A

THREDCO

3.34 12 NS SET THREAD PLUG GAGE GO ONLY P.D. = 3.2859 UNS 3.340"-12 UNS-2B 3B
