Set Plug Gages for Calibrating Ring Gages

GAGE ASSEMBLY CO.

1" 28 UN 2A SET THREAD PLUG GAGE 1.0 GO NO GO P.D.'S = .9756 & .9716 N-2A CHECK

P & W

6 32 NC 2A SET THREAD PLUG GAGE #6 .138 .1380 GO NO GO P.D.'S = .1169 & .1141 - DW0424BU

VARD

0.442 20 NS SET THREAD PLUG GAGE .442 NO GO ONLY P.D. = .4083 UNS QUALITY TOOL

4 48 NF 3 SET THREAD PLUG GAGE #4 .112 NO GO ONLY P.D. = .0969 UNF-3 CHECK

SCHRILLO

3 1/2 16 UN 3A SET THREAD PLUG GAGE 3.5 GO NO GO P.D.'S = 3.4594 & 3.4551 N-3A

4 40 NC 3 SET THREAD PLUG GAGE #4 .112 NO GO ONLY P.D. = .0941 UNC-3 CHECK

7/16 20 UNF 1A 2A MOD. SET THREAD PLUG GAGE .4375 NO GO ONLY P.D. = .4035 NF

SCHRILLO

3 1/8 16 2A SET THREAD PLUG GAGE 3.125 GO NO GO P.D.'S = 3.0827 & 3.0771 TOOL

3.36 40 NS SET THREAD PLUG GAGE GO ONLY P.D. = 3.3438 UNS 3.360"-40 QUALITY

SCHRILLO

5 1/2 12 X TOLLERENCE SET THREAD PLUG GAGE 5.5 GO ONLY P.D. = 5.4459 5 1/2"-12

PRATT & WHITNEY

3/4 20 NEF 1 SET THREAD PLUG GAGE .75 GO NO GO P.D.'S = .7160 & .7103 UNEF-1

9/16 18 UNF 3A SET THREAD PLUG GAGE .5625 GO ONLY P.D. = .5244 NF-3A 2 3 CHECK
