Set Plug Gages for Calibrating Ring Gages

BURDICK

2.35 40 NS SET THREAD PLUG GAGE GO ONLY P.D. = 2.3338 UNS 2.350 2.3500 CHECK

METRO

1.431 40 NS TAPERLOCK SET THREAD PLUG GAGE GO NO GO P.D. = 1.4150 CHECK 1.4310"

3/8 32 NEF 3A SET THREAD PLUG GAGE .375 GO ONLY P.D. = .3547 UNEF CHECK SETTING

PD

2 1/16 16 N 3A LEFT HAND SET THREAD PLUG GAGE 2.0625 GO ONLY P.D. = 2.0219 L.H.

BESLY

0.585 56 NS 3 SET THREAD PLUG GAGE .585 GO ONLY P.D. = .5734 585"-56 CHECK

1 3/4 32 NS SET THREAD PLUG GAGE 1.75 GO ONLY P.D. = 1.7297 1.750"-32 UNS UN 3A

HEMCO

0.42 56 NS 2 SET THREAD PLUG GAGE .42 GO ONLY P.D. = .4084 .420"-56 TOOL

PMC

5/8 18 UNF 3A SET THREAD PLUG GAGE .625 .6250 GO ONLY P.D. = .5889 INSPECTION - DW0008BU

PRATT & WHITNEY

NICE! 1 3/16 20 NS SET THREAD PLUG GAGE 1.1875 GO NO GO P.D.'S = 1.1447 & 1.1421

THREAD & GAGE

1 1/8 16 N 2 LEFT HAND SET THREAD PLUG GAGE 1.125 GO NO GO P.D.'S= 1.0844 1.0790

GODWIN GAGE

1 1/4 32 NS 2A SET THREAD PLUG GAGE 1.25 GO NO GO P.D.'S = 1.2297 & 1.2232 1.250

RITE-O

31/32 32 NS 3A MODIFIED SET THREAD PLUG GAGE .96875 P.D.'S = .9487 & .9456 NS-3A
